Markins QR-65P is Compatible with any Arca-Swiss type quick shoe(clamp). It is designed for precision panorama photography. Panning action is silky smooth. Employing our new Quick-Turn knob, it is extremely fast and efficient to open and close the clamp while offering excellent compatibility with most Arca Swiss type plate in the market. The Quick-Turn knob is 3 times faster than the traditional style.
It can be mounted directly on our new i-Type Q-Balls replacing the existing clamp with M6 screw. Or, it can be mounted on top of the existing Arca Swiss type clamp using the PE-1 Adapter that comes together as kit.
Small and light weight design is possible due to this powerful locking mechanism.
QR-65P is equipped with a newly optimized DDL (double disc lock) mechanism.
It is a device with dual wedge locking ring and disk of round shapes.
It needs less torque to lock the panning.
Axis of rotation also stays the same regardless of locking.
Position of locking knob is changed for easier control under a long nodal slide.
It is more comfortable to operate and will provide you with sharper images.
|Quick Turn Knob Style
|2.20 in (56mm)
|1.98 in (50.4mm)
Width (Close / Open)
|3.15 in (80mm) / 3.35 in (85mm)
|0.94 in (24mm)
1.14 in (29mm) w/ Adaptor Plate
|5.64 oz (160g)
6.31 oz (179g) w/ Adaptor Plate
